Motors
PEGASUS 1500
Motor for sectional or spring-balanced doors-8585896864613668085-s1.png)
-8585896864613668085-g6.png)
PEGASUS-1500 is the opener for sectional or spring- balanced garage doors up to 20 m² wide and 200 kg of weight. It is irreversible 24V motor for residential garage doors complete with embedded control panel and encounter type limit switch system. Quick and easy programming thanks to the keypad and display screen visible on the motor's cover.
Technical data
- Maximum doοr weight up to 200kg
- Motor power 24V
- Maximum door size 20 m²
- Maximum door height up to 2,4 meters
- Maximum thrust 1500N
- Motor rpm 1400
- Rail length 3,3 meters
- Protection rating IP40
